Standard Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.1 mm	2.2 s	0.5 s	25 s	3	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	5 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2.5 s	50 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Standard Resin V2 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.1 mm	2.2 s	0.5 s	25 s	3	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.1mm	3s	0.5 s	25 s	6	1	5 mm	20 mm/s	20 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2.5 s	50 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	2	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

ABS-Like Resin Pro 2 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	25 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	30 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	28 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	25 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Water-Wash Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.5 s	1 s	35 s	4	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	8 mm	2 mm/s	6 mm/s
Photon M3 Max	0.05 mm	3 s	2.5 s	35 s	6	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	4	8 mm	6 mm/s	6 mm/s
Photon M3 Plus	0.05 mm	1.5 s	0.5 s	23 s	4	6 mm	6 mm/s	6 mm/s
Photon M3	0.05 mm	2 s	0.5 s	23 s	4	6 mm	3 mm/s	4 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	8 mm	2 mm/s	3 mm/s
Photon D2	0.05 mm	2.5 s	1 s	28 s	5	5 mm	2 mm/s	3 mm/s
Photon Mono SQ	0.05 mm	2.3 s	0.5 s	23 s	6	5 mm	3 mm/s	3 mm/s
Photon Mono SE	0.05 mm	1.5 s	0.5 s	30 s	6	6 mm	4 mm/s	6 mm/s
Photon Ultra	0.05 mm	2 s	1 s	35 s	4	5 mm	2 mm/s	2 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	6 mm	4 mm/s	6 mm/s
Photon Mono X	0.05 mm	2 s	0.5 s	28 s	4	8 mm	2 mm/s	6 mm/s
Photon Mono	0.05 mm	2.5 s	0.5 s	40 s	4	6 mm	4 mm/s	6 mm/s
Photon S	0.05 mm	9 s	1 s	60 s	6	6 mm	3 mm/s	3 mm/s

ABS-Like Resin 3.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	3.2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	25 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	30 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	28 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	25 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Water-Wash ABS-Like Resin 3.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2.6 s	2 s	30 s	5	5 mm	8 mm/s	8 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	35 s	4	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	35 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	25 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	25 s	5	8 mm	6 mm/s	6 mm/s

High Speed Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Pro	0.01 mm	1.5 s	0.5 s	15 s	5	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7	0.01 mm	1.4 s	0.5 s	15 s	5	1	4 mm	15 mm/s	15 mm/s
Photon Mono M5s Pro	0.01 mm	1.9 s	0.5 s	15 s	5	1	3 mm	20 mm/s	20 mm/s
Photon Mono M5s	0.01 mm	1.9 s	0.5 s	15 s	5	1	3 mm	20 mm/s	20 mm/s
Photon Mono M5	0.01 mm	2 s	0.5 s	15 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X6Ks	0.01 mm	2.5 s	0.5 s	15 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X 6K	0.01 mm	2 s	0.5 s	18 s	6	1	6 mm	4 mm/s	6 mm/s
Photon M3 Max	0.01 mm	2.8 s	0.5 s	25 s	6	1	8 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.01 mm	2.5 s	0.5 s	25 s	5	1	6 mm	6 mm/s	6 mm/s
Photon Mono 2	0.01 mm	2.5 s	0.5 s	18 s	5	1	5 mm	4 mm/s	6 mm/s
Photon Mono X2	0.01 mm	2.5 s	0.5 s	18 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.01 mm	2 s	0.5 s	25 s	6	1	5 mm	4 mm/s	6 mm/s

High Clear Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Pro	0.05 mm	4 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	4 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	4 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	4 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	4 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	4 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	4 s	0.5 s	28 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	4.5 s	2.5 s	30 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	4 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	4 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	4 s	0.5 s	25 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	4 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Tough Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	2 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.1 mm	3 s	1 s	25 s	6	1	5 mm	20 mm	20 mm
Photon Mono M5s	0.05 mm	2.8 s	1 s	25 s	6	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	25 s	6	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	6	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	1 s	28 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	1 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

14K Texture Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	3 s	1 s	35 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.4 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono M5s Pro	0.05 mm	3.2 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	1 s	30 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	30 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	1 s	30 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	1 s	35 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	1 s	25 s	5	1	8 mm	4 mm/s	4 mm/s
Photon Mono 4K	0.05 mm	2 s	1 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Rigid 100 Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	2 s	35 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	2 s	25 s	4	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	2.8 s	1 s	23 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	1 s	23 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	23 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2 s	1 s	23 s	5	6 mm	4 mm/s	6 mm/s
Photon M3 Prerium	0.05 mm	2.5 s	1 s	25 s	5	6 mm	6 mm/s	6 mm/s
Photon M3 Max	0.05 mm	2.8 s	1 s	30 s	6	8 mm	4 mm/s	4 mm/s
Photon M3 Plus	0.05 mm	2 s	1 s	28 s	6	6 mm	6 mm/s	6 mm/s
Photon M3	0.05 mm	2.5 s	1 s	23 s	5	5 mm	4 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	5 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2 s	1 s	23 s	5	6 mm	4 mm/s	6 mm/s
Photon D2	0.05 mm	2.5 s	1 s	23 s	5	5 mm	2 mm/s	3 mm/s

Water-Wash ABS-like Resin V2 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	1.8 s	0.5 s	25 s	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.1 mm	3.6 s	0.5 s	35 s	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	35 s	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1s	30 s	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	4.2 s	0.5 s	35 s	1	5 mm	20 mm/s	20 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.1 mm	3.2 s	0.5 s	25 s	1	5 mm	20 mm/s	20 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	1	8 mm	6 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	30 s	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	25 s	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	1	6 mm	4 mm/s	6 mm/s

DLP Craftsman Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	2	1	8 mm	6 mm/s	6 mm/s
Photon M3 Max	0.05 mm	2 s	2.5 s	35 s	6	1	8 mm	3 mm/s	4 mm/s
Photon M3 Plus	0.05 mm	2 s	0.1 s	23 s	3	1	8 mm	2 mm/s	3 mm/s
Photon M3	0.05 mm	2 s	0.5 s	23 s	4	1	6 mm	3 mm/s	4 mm/s
Photon D2	0.05 mm	2.5 s	1 s	28 s	5	16	5 mm	2 mm/s	3 mm/s
Photon Ultra	0.05 mm	2 s	1 s	35 s	4	4	6 mm	5 mm/s	2 mm/s
Photon Mono X 6K	0.05 mm	2.5 s	0.5 s	40 s	8	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono X	0.05 mm	2 s	0.5 s	30 s	8	1	8 mm	4 mm/s	4 mm/s
Photon Mono	0.05 mm	2.5 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Plant-Based UV Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.5 s	1 s	35 s	4	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	8 mm	3 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	4	8 mm	6 mm/s	6 mm/s
Photon M3 Max	0.05 mm	3 s	2.5 s	35 s	6	10 mm	2 mm/s	3 mm/s
Photon M3 Plus	0.05 mm	1.5 s	0.5 s	23 s	4	6 mm	6 mm/s	6 mm/s
Photon M3	0.05 mm	2 s	0.5 s	23 s	4	6 mm	3 mm/s	4 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	8 mm	2 mm/s	3 mm/s
Photon D2	0.05 mm	2.5 s	1 s	28 s	5	5 mm	2 mm/s	3 mm/s

Tough Resin Ultra Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Pro	0.05 mm	2 s	2 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.1 mm	3 s	1 s	25 s	6	1	5 mm	20 mm/s	20 mm/s
Photon Mono M5s	0.05 mm	2.8 s	1 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	1 s	28 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	1 s	25 s	2	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	1 s	40 s	6	1	6 mm	4 mm/s	3 mm/s

Bio Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon Mono M7 Pro	0.1 mm	2.2 s	2 s	35 s	4	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.2 s	1 s	35 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.1 mm	3.8 s	1 s	35 s	6	1	5 mm	20 mm/s	20 mm/s
Photon Mono M5s	0.05 mm	2.8 s	1 s	35 s	6	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.1 mm	3 s	1 s	35 s	6	1	5 mm	20 mm/s	20 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	35 s	6	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	6	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	1 s	30 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	1 s	35 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	1 s	25 s	5	1	8 mm	4 mm/s	4 mm/s
Photon Mono 4K	0.05 mm	2 s	1 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Explore More Materials

View all

- £6.81 Top
PLA Basic
Texture Grey
Black
White
Clear
Classic Green
+14
Regular price £16.19

Sale price £16.19 Regular price ~~£23.00~~
Unit price per
- £4.91 Top
PLA High Speed
Pearl Black
Texture Grey
Bright White
Purple Opulence
Strawberry Pink
+5
Regular price £17.09

Sale price £17.09 Regular price ~~£22.00~~
Unit price per
- £8.40 Top
Standard Resin
Gray
Black
Clear
Light Beige
White
+7
Regular price £21.59

Sale price £21.59 Regular price ~~£29.99~~
Unit price per
- £11.70 Top
Water-Wash Resin 2.0
Gray
HD Gray
White
Black
Clear
+4
Regular price £24.29

Sale price £24.29 Regular price ~~£35.99~~
Unit price per
- £6.90 Top
PLA+
Texture Grey
Pearl Black
Bright White
Vibrant Yellow
Texture Silver
+16
Regular price £17.09

Sale price £17.09 Regular price ~~£23.99~~
Unit price per
- £9.70 Top
PETG
Texture Grey
White
Black
Orange
Purple
+16
Regular price £15.29

Sale price £15.29 Regular price ~~£24.99~~
Unit price per
- £5.50 Top
PLA Basic Refill
Black
Texture Grey
White
Red
Pink
+5
Regular price £14.49

Sale price £14.49 Regular price ~~£19.99~~
Unit price per
- £0.64 New
PLA+ Refill
Black
White
Texture Grey
Red
Blue
+5
Regular price £15.35

Sale price £15.35 Regular price ~~£15.99~~
Unit price per
- £6.90 New
PLA Galaxy
Galaxy Blue
Galaxy Green
Galaxy Brown
Galaxy Purple
Regular price £16.09

Sale price £16.09 Regular price ~~£22.99~~
Unit price per
New
PLA Marble
Marble White
Brick Red
Regular price £22.99

Sale price £22.99 Regular price
Unit price per
Water-Wash ABS-like Resin V2
Gray
Regular price £29.69

Sale price £29.69 Regular price ~~£41.99~~
Unit price per
- £14 Top
ABS-Like Resin Pro 2
Black
White
Gray
Clear
Blue
+4
Regular price £24.99

Sale price £24.99 Regular price ~~£38.99~~
Unit price per
PLA Special
Peach Pink
Tropical Turquoise
Interstellar Violet
Spring Leaf
Regular price £16.19

Sale price £16.19 Regular price ~~£20.00~~
Unit price per
Flash Sale
--: --: --: --

- £13 Flash Sale
High Clear Resin
Clear
Regular price £22.99

Sale price £22.99 Regular price ~~£35.99~~
Unit price per
PLA Silk Dual/Tri-Color
Black Gold
Black Blue
Black Green
Black Purple
Pink Gold
+7
Regular price £24.49

Sale price £24.49 Regular price ~~£36.99~~
Unit price per
DLP Craftsman Resin
Gray
Beige
Regular price £24.29

Sale price £24.29 Regular price
Unit price per
