Product Description
- Anycubic x Texas Instruments
- Consumer DLP® 3D Printer.
- Double Algorithms
- produces higher resolution prints.
- Laser Engraving Platform
- Experience a high success rate.
- Larger Printing Dimension
- 130.56x73.44x165mm.
- Technical Specifications
- ● Resin vat: One-piece design with scale line
- ● Build platform: Laser Carved Metal
- ● Exposure size: 95.42cm²
- ● Uniformity: 92%
- ● light transmittance: 92%
- ● Projector resolution: 2560*1440
- ● Control panel: 2.8" TFT touch-control
- ● Machine leveling: Manual(4-point)
- ● Exposure time: ≥2.5s/layer
- ● Data input: USB-A 2.0
- ● Rated power: 15W
- ● Printing size: 6.5 x 5.1 x 2.9 in. / 165 x 131 x 73 mm (HWD)
- ● Machine size: 17.2 x 9.3 x 8.9 in. / 438 x 236 x 226 mm(HWD)
- ● Machine weight: 8.8 lb./4 kg
-
*Anycubic Cloud service is not supported for Anycubic Photon D2.
- Consumer DLP® 3D Printer
- Using the DLP (Digital Light Processing) 3D printing technology, thousands of mirrors (DMD) concentrate the light with minimal diffusion directly to the bottom of the resin vat, thus improving the uniformity of light and achieving ultra-high precision printing results.
- Double Algorithms
- The application of the latest light uniformity algorithm increases the light uniformity to more than 92%. Combined with the anti-aliasing algorithm, the anti-aliasing effect is significantly enhanced, bringing more details to the miniatures.
- 10 Times Life Span
- Empowered by the DLP projector that of a life span of 20,000 hours, there is no need to replace screens like an LCD printer, which per screen of a life span of 2,000 hours, making you save up a significant amount of maintenance cost.
- Larger Printing Dimension
- Compared with Anycubic Photon Ultra, the printing volume of Anycubic Photon D2 increases by 62% to reach 130.56mm*73.44mm*165mm; and the printing area, rises by 55% to reach 95.42cm².
- Quiet Printing Experience
- The application of DLP® technology unlocks the possibility of designing a printer without a fan for heat dissipation as the light source modules only generate little heat while operating. Bringing a quiet and soothing printing experience.
- Low Energy Consumption
- The Digital Light Processing (DLP®) technology can efficiently utilize the light source, which makes the printer power as low as 15W, only 1/4 the power of LCD printers.
- Greater Adhesion
- The dedicatedly designed Laser engraving pattern significantly enhances the adhesion of the printing platform, bringing a better printing success rate.
- No Fear for a Close Check
- With DLP® technology, Anycubic Photon D2 DLP resin 3D printer handles more accurate and precise 3D printing, capturing more vivid details. And you will achieve better effect with Anycubic DLP Craftsman Resin which is exclusive and high accuracy resin for DLP printers.
- Application Scenarios
- Whether it is intricate craftsmanship and individual tailoring in the field of jewelry design, the need for high precision in dental applications, or even the demands of professionals and hobbyists for a wide range of models and artworks.
Parts List
User manual
Funnel
Tool set
USB memory
Scraper
Resin vat
Platform
Power cord
Glove
|
|
|||
| Printing Technology | DLP (Digital Light Processing) | LCD-based SLA Printing | LCD-based SLA Printing |
| Screen Life-span |
≤20,000 hours | ≤2,000 hours | ≤2,000 hours |
| Light Transmittance |
92% | 4% | 6% |
| Rated Power |
15W | 55W | 120W |
| Machine Weight |
~4kg | 7kg | 11kg |
| Machine Size |
438*236*226mm | 425*269*256mm | 475x290x270mm |
| Build Volume |
131*73*165mm(1.58L) | 180*164*102mm(2.99L) | 245*197*122mm(5.89L) |
-
- Photon D2
- Printing Technology：DLP
- Screen Life-span: ≤20,000 hours
- Light Transmittance: 92%
- Rated Power: 15W
- Machine Weight: ~4kg
-
- Photon M3
- Printing Technology：LCD
- Screen Life-span: ≤2,000 hours
- Light Transmittance: 4%
- Rated Power: 55W
- Machine Weight: 7kg
-
- Photon Mono X 6K
- Printing Technology：LCD
- Screen Life-span: ≤2,000 hours
- Light Transmittance: 6%
- Rated Power: 120W
- Machine Weight: 11kg
