Sorry, Anycubic Photon Mono X 6K are sold out.
Upgrade to our latest model Anycubic Photon Mono X 6Ks.
Product Description
- Fast printing speed
- Photon Mono X can print a typical 120mm / 4.7in. model in 1.5 hours.
- High light transmittance
- High light transmittance makes quick forming possible.
- Large build volume
- print up to 9.6 x 7.8 x 4.8 in. / 245 x 197 x 122 mm (HWD) at a time.
- Sharp edges and corners
- Adopting an industry-leading screen with 350:1 contrast ratio.
- Technical Specifications
- ● Exposure screen: 9.25’’ monochrome
- ● Printing volume: 199.1 oz. / 1.6 gal. / 5.9 L
- ● Light transmittance: 6%
- ● Contrast ratio: 350:1
- ● Light source: Parallel matrix (LED x 40)
- ● Power density: 5,000 - 6,500 μw/cm² / 34,150 - 44,395 lux
- ● Printing accuracy: 5,760 x 3,600 px (6K)
- ● Horizontal resolution: 34 μm
- ● Printing speed: Max 80mm/h
- ● Control panel: 3.5’’ TFT touch-control
- ● Data input: USB-A 2.0 / LAN
- ● Power supply: 120W
- ● Screen area: 38.22 in² / 248.75 cm²
- ● Machine dimensions: 18.7 x 11.4 x 10.6 in. / 475 x 290 x 270 mm (HWD)
- ● Machine weight: 24.3 lb. / 11 kg
- For Freedom to Make
- Anycubic Photon Mono X 6K can print up to 9.6 x 7.8 x 4.8 in. / 245 x 197 x 122 mm (HWD) at a time, similar dimensions to a super midi rugby ball. 199.1 oz. / 1.6 gal. / 5.9 L total build volume leaves more space and freedom for you to make any shapes of cubic.
- 6K Vivid Details
- With 5,760 x 3,600 px resolution, Anycubic Photon Mono X 6K's screen has a total number of over 20 million pixels, which is 125% higher than Anycubic Photon Mono X and its rivals' 4K resolution screen. High resolution brings vivid details to your 3D models.
- Sharp Edges and Corners
- Adopting an industry-leading screen with 350:1 contrast ratio, 75% higher than Anycubic Photon X and its rivals' 200:1, Anycubic Photon Mono X 6K provides your 3D models with extremely sharp and clear edges and corners.
- Protect What Matters
- In order to better protect its premium screen, Anycubic Photon Mono X 6K added a dedicated and replaceable anti-scratch film above the screen itself, making that expensive screen much more durable than its rivals.
- Print, One Step Ahead
- With an impressive print speed at ≤ 80 mm/hr. / 3.15 in./hr., Photon Mono X can print a typical 12cm / 4.7in. model in 1.5 hours, which takes 4.5 hours less than Photon's 6 hours, and 1.5 hours less than its rivals' 3 hours. Fast printing saves your time wasted on waiting.
- Powerful Light Matrix
- 40 bright LED lights are placed into a matrix to make up a powerful and parallel light source, so that Anycubic Photon Mono X 6K can provide ≥90% light uniformity and ≤ 44,395 lux power density to each layer, making fast printing possible.
- High Light Transmittance
- Anycubic Photon Mono X 6K is equipped with an industry leading screen with 6% light transmittance, which is 200% higher than Anycubic Photon Mono X and its rivals' 2%. High light transmittance makes quick forming possible.
- Universal Compatibility
- With 30%-100% light power regulation, Anycubic Photon Mono X 6K supports not only ordinary 405nm UV resins, but also special resins. In addition, adjusting the light power appropriately can extend the lifespan of both the screen and light significantly.
- 9.25'' Large Screen
- Anycubic Photon Mono X 6K is equipped with a large 9.25'' screen, which is 185% larger than Anycubic Photon's 5.5'' screen, 138% larger than a common 6'' screen, and 8% larger than Photon Mono X and its rivals' 8.9'' in screen area.
Parts List
User Manual
Funnel
Tool set
SD-Card Reader
Scraper
Resin Vat
Platform
Power Cord
LCD Screen Protector
Mask
Glove
| Machine Weight | 10.8kg | 4.3kg | 11kg |
| Machine Size | 475x290x270mm | 383x227x222mm | 475x290x270mm |
| LCD Resolution | 3840x2400px(4k) | 3840x2400px(4k) | 5760x3600px(6k) |
| LCD Size | 8.9’’ monochrome | 6.23’’ monochrome | 9.25’’ monochrome |
| XY Resolution | 50 microns | 35 microns | 34 microns |
| Z axis Accuracy | 10 microns | 10 microns | 10 microns |
| Build volume | 245xx192x120mm(5.6L) | 165x132x80mm(1.74L) | 245x197x122mm(5.89L) |
| Max.Printing Speed | 60mm/h | 50mm/h | 80mm/h |
-
- Anycubic Photon M3
- 7,6" 4K+ LCD
- Build volume [LxBxH]: 163 x 102 x 180 mm
- Material: 405nm UV Resin
- Printing speed: 50mm/h
-
- Anycubic Photon M3 Plus
- 9,25" 6K LCD
- Build volume [LxBxH]: 197 x 122 x 245 mm
- Material: 405nm UV Resin
- Printing speed: 100mm/h
-
- Anycubic Photon M3 Max
- 13,6" 7K LCD
- Build volume [LxBxH]: 425 x 269 x 256 mm
- Material: 405nm UV Resin
- Printing speed: 60mm/h
