Rigid 100 Resin*1+Texture Resin*1+Plant-based Resin*1+Water-Wash Resin*1
Rigid 100 Resin:Anycubic Photon Mono M7 Pro works best with Rigid 100 Resin,as M7 Pro features an Dynamic Temperature Control Resin Vat thatenhances resin flow and helps reduce resin's viscosity,thus ensuring reliable, rapid printing with Rigid 100 Resin.
Texture Resin:Superior Precision. The 14K high-precision resin, ideal for miniatures and intricate scenes, delivers 0.15mm accuracy with ultra-fine tips at 0.02mm—half the width of a human hair. It offers 40% higher precision than any other existing 14K resins on the market.
Plant-based Resin:The safe formula, the choice of many different colors and highly detailed performance are ideal for printing different prints applied in animation, detailed model, cultural and creative hand-made models, prototype parts, education, etc.
Water-Wash Resin:The printing accuracy is improved, due to the low shrinkage rate that allows every model to be printed with precise details. To ensure the stable performance of the resin, please take out the model in time after cleaning to avoid deformation caused by the model soaking in water for a long time.
- Shake the liquid resin before use.
- Clean the resin tank and the molding platform to keep the bottom of the resin tank in lighttransmission.
- Unscrew the cap and add it to the resin tank according to the equipment requirements.
- Select the correct print parameters and settings for printing.
- After printing, please use the matching tools for post-processing, including blade, diagonalpliers, tweezers, containers, gloves.
- ethanol(≥95%), lactate or isopropyl alcohol cleaning solution.
- A. Remove the printed model from the molding platform with a blade.
- B. Submerge the model in the cleaning solution, rinsed or ultrasonically washed, then takenout and drained; ANYCUBlC Wash and Cure machines are suggested to ensure better effect.
- C. Proper processing, such as removing support, polishing, coloring, etc.
- The ideal condition for storing uncured resin is a cool, dark place at room temperature and protect from light to avoid high temperature or sunlight.
- Suggested operating temperature is 18-35'c, and a low temperature may affect the printing effect, thus, the resin can be properly preheated before use (not more than 60°C).
- If the resin pigment settles, it can be used after stirring or shaking.
- In order to ensure the performance of the resin, please take out the model in time after cleaning to avoid the model soaking in water for a long time.
- To ensure the mechanical properties of the model, please perform post-curing in time after cleaning and drying.
- To ensure the ideal performance of the curable material, it is necessary to control the intensity and time of the light source after curing. Therefore, the following steps are recommended:
- 1. The intensity of mercury lamp or LeD light source is 5-10mW/m?, and the duration is no more than 1 hour (self-regulation)
- 2. The exposure time in the sun (summer) is around 1 hour
- 3. Proximity or long-term exposure under strong light sources such as high-power high-pressure mercury lamps is prohibited
- 4. lt is recommended to print in a dark room or be covered with a lid while printing as resin is a photosensitive material.
